• Three sizes available 16″ x 20″, 16″ x 16″, 11″ x 15″
• Easy-to read digital time, temperature, and pressure display for accurate, consistent printing
• Over-the-Center Pressure Adjustment for even, edge-to-edge heat and pressure, regardless of substrate thickness

• Wide opening for easy layout
• Space-saving clamshell design
• Patented magnetic auto-open feature prevents over-application
• Locks down easily with patented magnetic assist, causing less fatigue on wrists and shoulders
• Twin Timer™ allows user to pre-set individual time settings for two-step application or for pre-heating and application
• Optional interchangeable lower platens available
• 11 x 15 Electrical Options:
• 120 v; 8.3 amps; 1000 w
• 240 v; 4.5 amps; 1000 w
• 16 x 16, 16 x 20 Electrical Options:
• 120 v; 15 amps; 1800 w
• 240 v; 7.5 amps; 1800 w
• Must have dedicated circuit breaker
• Proudly made in the USA

Universal Features

• Made in the USA
• Cast-in tubular heating
• Powder coated finish
• UL/ULC/CE

Details

• Actual weight: 87 lbs.
• Ship weight 100 lbs.
• Actual Dimensions: 29" x 17" x 17"
• Ship dim. 36" x 25" x 21"

Warranty

• Heating Element - Lifetime
• Framework - 5 years
• Circuit Board - 2 years
• Parts & Labor - 1 year

Optional Platens

• 7" round
• 6" x 10"
• 8" x 10"
• 11" x 15"
