This HLK model features the latest Direct Drive system with a servo motor fitted as part of the sewing machine head; this improves sewing acceleration while greatly reducing power transmission losses and results in energy savings of up-to 40% when compared with conventional machines. Sewing patterns, stitch numbers and stitch length can be set with-in the sewing area using the included hand held programming unit with colour touch screen and easy to use icon driven menus. The adoption of the universal serial bus (USB) makes programming, updating and storage easier. Inexpensive USB memory sticks are readily available.
This model is a subclass of High lead electronic pattern sewing machine series. Equipped with high accurate electronic control system and high performance servo motor, sewing pattern and sewing parameters such as stitch number, stitch length, etc can be set at discretion within the range by a programmer. It can also be operated by inputting the pre-programmed stitching pattern through USB connection. With the features of precise structure design, reliable driving and convenience in pattern input. Pattern revision, pattern storage and pattern recall. It is a large size electronic pattern sewing machine specially designed for stitching extra heavy duty articles such as leather, webbing belt, etc.
| Category | HLK-3020 | HLK-3020(TH) |
|---|---|---|
| Max Sewing Speed | 2700 r.p.m. | 800 r.p.m. |
| Speed preset | N/A | 100-800 r.p.m. at discretion |
| Stitch length | 0.1 - 12.7 mm | 0.1 - 12.7 mm |
| Needle bar stroke | 41.2 mm | 56 mm |
| Thread take-up lever stroke | 73 mm | 96 mm |
| Presser foot lift | 20 mm | Outer presser foot 30mm (pneumatic) Middle presser foot 20 mm |
| Sewing area | 300mm in X-way (Horizontal), 200mm in Y-way (vertical) | 300mm in X-way (Horizontal), 200mm in Y-way (vertical) |
| Needle Size | DPx17 #18 (standard) | DY x 3 26# |
| Hook | Shuttle hook | KSP-204N Large Shuttle hook |
| X-Y Driving mechanism | Interim or continuous switch among stepping motors, racks and guide rails | Interim or continuous switch among stepping motors, racks and guide rails |
| Motor | 220V 550W Servo motor | 220V 750W Servo motor |
| Enlargement/Reduction ratio | N/A | X-Y 10%-200% (0.1%/step) |
Compare models and choose your model in the dropdown below the add to cart.
