SINGLE-NEEDLE FREE-ARM EMBROIDERY

With its single needle and free arm, the Capella is engineered to embroider an array of designs in hard-to-reach areas such as inside pockets, hats, tote bags, and more.

7-7/8” X 11-3/4” EMBROIDERY FIELD

The Capella machine gives you 7-7/8" x 11-3/4" of generous space for your embroidering needs.

EMBROIDERY CROSSHAIR POSITIONING LASER

Use the crosshair positioning laser to preview the layout of your embroidery design; then adjust the position and angle for precise alignment.

TRUVIEW™ DESIGNER

This high-definition TruView™ LCD color touchscreen brings your embroidery designs to life. It displays more than 260,000 colors, providing a bold, vivid image to help you edit and perfect each design.

QUICK-SET, BUILT-IN BOBBIN WINDER

The Capella bobbin system includes an automatic bobbin winder with its own motor. The winder seat holds the thread in place and stops automatically when the bobbin is full.

AUTOMATIC NEEDLE THREADER

Stitch with worry-free threading with the automatic needle threader. It threads your needle for you!

38 BUILT-IN FONTS

38 built-in, editable fonts to create distinct projects. Font designs include large floral alphabet, Greek letters, large appliqué alphabet, and a Baby Lock exclusive font.

175 BUILT-IN DESIGNS

You’ll always have something to embroider with Capella’s huge selection of built-in designs that includes XX exclusive designs from Baby Lock. The design library features large thumbnails to make finding the right match even easier.

EMBROIDER AT 1,000 STICHES PER MINUTE

The Capella stitches up to 1,000 stitches per minute. Embrace larger, multicolored designs and watch them stitched in no time!

CONVENIENT BOBBIN SYSTEM

Never remove your embroidery hoop again! This front-loading bobbin system with a vertical hook makes bobbin changes easy and quick.

USB FLASH DRIVES (1 TYPE A, 1 TYPE B)

Use USB connectivity to quickly import designs to your machine from a computer, flash drive, or CD-ROM. The Capella USB flash drives support multiple design software formats.

MULTI-LINE TEXT AND JUSTIFICATION

Create multiple lines of text quickly and easily without the need for constant rehooping. You also can center or justify your text alignment to precisely achieve the look you desire.

Machine Features:

• Built-in memory (1 MB)
• Bobbin system: front loading, vertical rotary hook
• Quick-Set, built-in bobbin winder with independent motor
• Can use pre-wound bobbins (Class L)
• Push button, automatic needle threader
• 2 LED lights to illuminate work area
• Upper thread breakage sensors
• Manual tension controls
• Automatic thread trimmer (upper and lower)
• Start/Stop button with lock feature
• On-screen speed control while stitching
• 4-thread spool stand
• Built-in holder with stylus

Convenience Features:

• Built-in embroidery designs
  • 175 designs
  • 39 fonts
  • 1 monogram font
  • 120 frame combinations
• Combine embroidery designs onscreen
• Character/text array function
• Multi-line text
• Character spacing
• Pattern rotation (1°, 10°, and 90°)
• Design size change (10% reduction and 20% enlargement) on most designs
• Needle forward and reverse position placement (1, 10, 100, or 500 stitch increments) and by color
• Design duplication
• Color sorting on non-overlapping designs
• Automatic basting
• Mirror imaging
• Change color selections within designs
• Continuous border capabilities and color sorting on border designs
• Monochrome option for embroidery designs
• Instant needle edge placement (9 starting and ending positions)
• Hoop sensor advises hoop size for chosen design

Included Accessories:

• Touch pen (stylus)
• USB cable
• Accessory case
• Spool
• Prewound bobbins
• Spool caps
• Metal bobbins
• Embroidery frame holder A
• Embroidery frame holder B
• Embroidery hoops:
  • 7-7/8" x 11-3/4" (200mm x 300mm)
  • 4" x 4" (100mm x 100mm)

Specifications:

• BUILT-IN DESIGNS - 175
• EMBROIDERY PATTERN MEMORY - Yes
• NUMBER OF HOOPS INCLUDED - 2
• MAXIMUM EMBROIDERY FIELD SIZE - 7-7/8" x 11-3/4"
• ON-SCREEN EDITING - Yes
• EMBROIDERY SPEED - 1000 spm
• ROTATION CAPABILITY - Yes
• MACHINE WEIGHT ONLY - 68 lbs
• TOTAL NUMBER OF USB PORTS - 1
• COMBINE DESIGNS - Yes
• DATA INPUT TYPES - .pes, .phc, .dst
• FRAME PATTERNS - 120 combinations
